PostPosted: 03/07/2023 16:22    Post subject: SIMATIC CN Engineering Tool V2.5 CNET Reply with quote
SIMATIC CN Engineering Tool V2.5 (CNET) for commissioning the SIMATIC CN 4100 V2.5
https://support.industry.siemens.com/cs/document/109814147/
CNET can run on current standard PCs, programming devices or laptops. The connection to a SIMATIC CN 4100 can be established via an Industrial Ethernet cable or the existing network structure.
The programming device or the PCS 7 engineering station with CNET should be in the same network as the SIMATIC CN 4100.
The following ports must be activated for a configuration across network boundaries:
SSH and SFTP port 22
TCP Port 11555
The PC station should meet the following minimum requirements:
4-core CPU with 2.0 Ghz
At least 2 GB RAM
10 GB free hard drive space (SSD recommended)

2.2 Software
CNET 2.5 has been approved for the following operating systems:
Windows 10 Enterprise LTSC 2019 (64 bit)
Windows Server 2016 (64 bit)
Windows Server 2019 (64 bit)
The following SIMATIC PCS 7 versions and station types have been released:

As of SIMATIC PCS 7 9.0 SP3 engineering station / single station
Download
https://support.industry.siemens.com/cs/attachments/109814147/cn4100-i386-1.12.0-88d02b2.zip
https://support.industry.siemens.com/cs/attachments/109814147/CNET-2.9.15-windows-x64.zip
https://support.industry.siemens.com/cs/attachments/109814696/cnet_en-US_en-US.pdf

Overview of SIMATIC S7-4100 manuals
https://support.industry.siemens.com/cs/document/109813162/
Back to top
View user's profile Send private message
valz
Member 3
Member 3
valz

Joined: 26 Jul 2015
Posts: 771
PostPosted: 03/07/2023 16:22    Post subject: SIMATIC CN 4100 - Open Source Software (OSS) Reply with quote
SIMATIC CN 4100 - Open Source Software (OSS)
https://support.industry.siemens.com/cs/document/109801220/
In this download entry you will find the Open Source Software (OSS) of the firmware of the SIMATIC CN 4100, for the connection of systems from third-party manufacturers.

https://support.industry.siemens.com/cs/attachments/109801220/Opensource_V25.zip
Back to top
View user's profile Send private message
valz
Member 3
Member 3
valz

Joined: 26 Jul 2015
Posts: 771
PostPosted: 03/07/2023 16:24    Post subject: SIMATIC CN 4100 in SIMATIC PCS 7 Reply with quote
Integration of third-party systems, package units, safety integrated systems (SIS) with SIMATIC CN 4100 in SIMATIC PCS 7
https://support.industry.siemens.com/cs/document/109801222/
The integration of third-party systems, package units, safety integrated systems (SIS) and other standard communications protocols like OPC UA and MODBUS/TCP requires a user-friendly, scalable and powerful solution. The SIMATIC CN 4100 communication node was developed to serve as a gateway to these applications for medium- and large-scale signal structures.
This application example describes the following use cases:

Commissioning and initial configuration of the SIMATIC CN 4100
Configuration of communication (OPC UA / MODBUS/TCP) with external devices via SIMATIC CNET
Integration in SIMATIC PCS 7
Diagnosis and troubleshooting

The integration is demonstrated using the example of an external OPC UA server and a MODBUS/TCP slave with different data types. Negru box communication with the AS 410 is carried out via the external Ethernet CP443-1 as an example. The data from the CN 4100 is transferred to the AS 410 using the S7 protocol and processed here using the PCS 7 library provided.

SIMATIC CN Engineering Tool V2.5 CNET SIMATIC CN Engineering Tool V2.5 CNET

Documentation
https://support.industry.siemens.com/cs/attachments/109801222/109801222_CN4100_en.pdf
Excel-tool for offset calculation
https://support.industry.siemens.com/cs/attachments/109801222/109801215_Offset_Calculation_V0_2.xlsx
Demo Projects
MODBUS/TCP
https://support.industry.siemens.com/cs/attachments/109801222/PCS_7_MODBUS_TCP.zip
https://support.industry.siemens.com/cs/attachments/109801222/CNET_MODBUS_TCP.zip

OPC UA
https://support.industry.siemens.com/cs/attachments/109801222/CN4100_OPC_UA.zip
https://support.industry.siemens.com/cs/attachments/109801222/CNET_OPC_UA.zip
Back to top
View user's profile Send private message
valz
Member 3
Member 3
valz

Joined: 26 Jul 2015
Posts: 771
PostPosted: 03/07/2023 16:25    Post subject: SIMATIC PCS 7 Library for SIMATIC CN 4100 Reply with quote
SIMATIC PCS 7 Library for SIMATIC CN 4100
https://support.industry.siemens.com/cs/document/109801221/
This library contains channel blocks, for getting the IO Data from the CN 4100. The structure of the PCS 7 CN 4100 Library is based on the APL.

The transfer of the data (writing from the CN 4100 to the global DBs and reading from the global DBs to the CN 4100) is completely handled in the CN 4100 with PUT/GET communication. Incoming I/O data from the CN 4100 gateway is stored in PCS 7 compliance in global DBs.

Downloads
https://support.industry.siemens.com/cs/attachments/109801221/Cn4100_Library_V1.0.1.zip
https://support.industry.siemens.com/cs/attachments/109801221/CN4100_driver_blocks_PCS_7_V1_1.pdf
Back to top
