Safe temperature monitoring up to SIL 1 or PLC with a 3RS2 temperature monitoring relay
https://support.industry.siemens.com/cs/document/109780387/
The temperature of bodies that can develop a corresponding heat and are freely accessible must be monitored. If a defined temperature limit is exceeded, the 3RS2 switches the overheated motor off via a contactor in a safety-oriented manner.

Safe temperature monitoring3RS2 temperature monitoring relay Safe temperature monitoring3RS2 temperature monitoring relay

Safe temperature monitoring3RS2 temperature monitoring relay Safe temperature monitoring3RS2 temperature monitoring relay

According to EN ISO 12100, Annex B, there is a potential hazard "burns due to atingere with high-temperature material", which must be evaluated and reduced if necessary during the risk assessment. The temperature of bodies that can develop a corresponding heat and are freely accessible must be monitored. The 3RS2 switches off the overheated motor directly via a contactor in a safety-oriented manner up to SIL 1 / PL c if a defined temperature limit value is exceeded, without the need for an intermediate safety relay.

A 3RS26 or 3RS28 temperature monitoring relay from the 3RS2 series is used here. These two device types can be used in safety applications up to SIL 1 / PLC.

https://support.industry.siemens.com/cs/attachments/109780387/TemperatureMonitoring_3RS2_SIL1_en_V2.zip
https://support.industry.siemens.com/cs/attachments/109780387/Wiring_TemperatureMonitoring_3RS2_SIL1.zip

https://anonfiles.com/ZaY6Fcp8vd/TemperatureMonitoring_Door_Tumbler_3RS2_SIL1_en_V2_zip
https://anonfiles.com/b8Z2Fbpevb/Wiring_TemperatureMonitoring_Door_Tumbler_3RS2_SIL1_zip
https://anonfiles.com/f4Z6F6p4v0/manual_temp_monitoring_relay_en-US_pdf

https://ulozto.net/tamhle/xRZkpPW8Nufs/
