 Posted: 27/05/2019 19:12 Post subject: PN/J1939 LINK – Configuring data exchange |
 |
|
PN/J1939 LINK – Configuring data exchange
https://support.industry.siemens.com/cs/document/109760972/pn-j1939-link-%E2%80%93-configuring-data-exchange
This application example explains the operation of two PN/J1939 LINKs. During
configuration, the following is considered:
• How to use cyclic data communication
• How to use acyclic data communication
• How the events are transmitted
The PN/J1939 LINKs are connected via PROFINET to the SIMATIC S7 controller.
The configuration takes place on a PC with installed TIA Portal.
The "PN_J1939_Communication_V15.zip" file contains the application example for TIA Portal V15.
https://support.industry.siemens.com/cs/attachments/109760972/PN_J1939_Communication_V15.zip
https://support.industry.siemens.com/cs/attachments/109760972/109760972_network_transitions_pnj1939_link_en.pdf |
|
