 Posted: 30/06/2020 16:45 Post subject: install .NET Framework 3.5 on SIMATIC IPC |
 |
|
How do you install .NET Framework 3.5 on SIMATIC IPCs (for WinCC TIA Portal, STEP 7 TIA Portal or WinCC V7, for example)?
https://support.industry.siemens.com/cs/document/109745988/how-do-you-install-net-framework-3-5-on-simatic-ipcs- (for-wincc-tia-portal-step-7-tia-portal-or-wincc-v7-for-example
Retro-installing .NET Framework 3.5 in Windows 10, Windows Server 2012 or Windows Server 2016
Description
The requirement for installing and running specific programs is Microsoft .NET Framework 3.5. However, this version of Framework is not installed on your computer and you have to retro-install it.
Validity
Windows 10 Enterprise 2015 LTSB
Windows 10 Enterprise 2016 LTSB
Windows 10 Enterprise CBB/SAC
Windows 10 Enterprise 2019 LTSC
Windows Server 2012 R2 (64 bit)
Windows Server 2016 (64 bit)
Windows Server 2019 (64 bit)
| Code: | 1) Install the option ".NET Framework 3.5" via Windows Features (internet connection required)
Right-click "Start" to start "Programs and Features".. The "Programs and Features" window opens.
Click "Enable or disable Windows features". The "Windows Features" window opens.
Select the option ".NET Framework 3.5 (includes .NET 2.0 and 3.0)".
Confirm with "OK". The ".NET Framework 3.5" option is installed.
2) Install with a Windows 10 standard data carrier (ISO image)
Download the MediaCreationTool for Windows 10 from Microsoft onto your computer and use it to create a Windows 10 standard ISO image, 32-bit or 64-bit depending on your SIMATIC IPC operating system. Download MediaCreationTool.
Incorporate the image in your SIMATIC IPC (mount) or burn the image file onto an empty DVD.
To install .NET Framework 3.5 proceed as for installation via the command line (DISM), see 6).
3) Install with a "Restore" DVD or "Documentation & Drivers" DVD or the USB stick provided with the IPC
Insert the "Restore" data medium or the "Documentation & Drivers" DVD of your IPC.
Start the "Documentation & Drivers" suite by running "START_DocuAndDrivers.CMD".
Navigate to "Software" and where appropriate click "Optional Windows Features".
Install .NET Frameworks 3.5 for Windows 10.
The ".NET Framework 3.5" option is installed.
4) Install with a "Recovery" DVD
Insert the "Recovery" DVD of your SIMATIC IPC into the optical drive.
To install .NET Framework 3.5 proceed as for installation via the command line (DISM), see 6).
5) Notes on Windows Server 2012 R2
To be able to install .NET Framework 3.5 you have to set the system language to English and uninstall all language packages except English, see Microsoft Docs (English).
Change the System and User Language. Insert the "Restore DVD" of your SIMATIC IPC into the optical drive and boot from the data carrier.
In the menu you select and start the "Windows Console".
Start the DiskPart program and define the drive letter of the Windows installation. For this you enter the following command sequence in the Windows Console:
diskpart
list volume
Note the drive letter of the Windows installation from the "Let" column, "C", for example. In the as-delivered status the Windows installation is on the partition with the designation "System".
Quit DiskPart. For this you enter the following command in DiskPart:
exit
Using the DISM tool you set all the language settings to English. For this you call the DISM with the following parameters. Replace the drive letter "C" in the example with the drive letter of your Windows installation.
dism /Set-AllIntl:en-US /Image:C:\
Remove the DVD and shut down your SIMATIC IPC.
Boot Windows Server 2012 R2.
Uninstall the language packages except English. For this you start the Setup program to install or uninstall language packages (LPKSetup). Execute the following command with administrator rights:
Lpksetup
Follow the instructions of the wizard for uninstalling the language packages and uninstall all the language packages except English.
>To install .NET Framework 3.5 proceed as for installation via the command line (DISM), see 6).
6) Installation via the command line (DISM)
On the inserted data carrier search for the file "microsoft-windows-netfx3-ondemand-package.cab".
Note the directory path where the file is located ("F:\x64\sources\sxs", for example).
Start the Windows input prompt with administrator rights by executing the following command as administrator:
cmd
Install the .NET Framework. For this you call the "Deployment Image Servicing and Management" (DISM) tool with the following parameters. Replace the path designation "<path>" with the path of the "*.cab" file from Step 1.
dism /online /enable-feature /featurename:netfx3 /all /source:<path> /limitacces
Example
dism /online /enable-feature /featurename:netfx3 /all /source:F:\x64\sources\sxs /limitaccess
The ".NET Frame
|
|
|
