 Posted: 12/09/2023 18:21 Post subject: Connecting S7 stations to an MQTT Broker via SIMATIC Cloud |
 |
|
Connecting S7 stations to an MQTT Broker via SIMATIC CloudConnect 716
https://support.industry.siemens.com/cs/document/109820894/
The Industrial IoT Gateway SIMATIC CloudConnect 7 enables data to be read simply and reliably from S7-based devices and transfers it to a wide range of cloud platforms using the standardized MQTT protocol.
This application example shows how you can connect several S7 stations to the SIMATIC CloudConnect 716 (CC716) gateway via Industrial Ethernet and PROFIBUS/MPI. Then the connection to an MQTT broker (here Mosquitto) is configured. The S7-1500 with CP 1545-1 is also connected to the MQTT broker. The data points can subsequently be read and written via any MQTT client (here MQTT.fx).
Downloads
https://support.industry.siemens.com/cs/attachments/109820894/109820894_CloudConnect_MQTT_DOC_V20_en.pdf
https://support.industry.siemens.com/cs/attachments/109820894/109820894_CloudConnect_MQTT_PROJ_V20.zip
https://ulozto.net/tamhle/21mVtS1ZYoeb/
[URL=https://www.file-upload.net/download-15186948/109820894_CloudConnect_MQTT_DOC_V20_en.pdf.html]109820894_CloudConnect_MQTT_DOC_V20_en.pdf[/URL]
[URL=https://www.file-upload.net/download-15186947/109820894_CloudConnect_MQTT_PROJ_V20.zip.html]109820894_CloudConnect_MQTT_PROJ_V20.zip[/URL] |
|
